Leica GeoMoS
Leica GeoMoS
Contact us for price
Get in touch with our experienced sales team to order or discuss any products.
Tel: 01480 402250
Email: sales@sccssurvey.co.uk
Hire enquiries
Tel: 01480 402269
Email: hires.geo@sccssurvey.co.uk
Ideal for...
Leica GeoMoS is a multi-purpose automatic deformation monitoring software that can be used for:
- Structural deformation monitoring (e.g. dams, tunnels, bridges, high-rise buildings, construction)
- Landslide and settlement detection (e.g. mining, rock falls, volcano slopes, subsidence)
- Automated surveys (e.g. continuous, automated measurements)
- And many more..
Details and features of GeoMos Software
Scalable and flexible
The Leica GeoMoS software is comprised of two main applications called Monitor and Analyzer.
- Monitor is the online application responsible for the sensor control, collection of data, computation and event management.
- Analyzer is the offline application responsible for the analysis, visualization and post-processing of the data.
GeoMoS stores all measurements and results in an open SQL database. The data can be accessed both locally and remotely, using either GeoMoS Analyzer or third party software.
The Leica GeoMoS software is highly customizable allowing you to purchase only the functionality you require. The sensor license concept means that the software scales with the number and type of sensors you have connected. Additional functionality can easily be added later should your needs change.
Sensor Connections
Leica GeoMoS offers the ability to connect geodetic (total stations and GNSS sensors) and geotechnical sensors to understand the reasons of any detected movement and to improve the prediction of failure.
- Total stations: Leica TPS1100, TPS1200, TPS1200Plus, TCA1201M, TPS1800 and TPS2003 Series
- GNSS sensors: Leica GPS System 500, GPS System 1200, GMX900 Series
- Connection to Leica GNSS Spider for advanced GNSS monitoring
- Levels: Leica DNA and Leica Sprinter
- Tilt sensors: Leica Nivel20 and Nivel200 Series
- Meteorological sensor (e.g. temperature, pressure)
- An interface to Campbell Scientific dataloggers, that can support most commercially available geotechnical sensors to measure environmental effects and conditions (e.g. extensometers, piezometers, strain gauges, inclinometers, thermometers, barometers, rain gauges, and many more)
In addition to the traditional serial based communication Leica GeoMoS also includes a direct TCP/IP communication interface to support Ethernet technology and mobile networks.
Software Features
- Project concept for periodic deformation monitoring projects
- Data storage in an open SQL database
- Parallel use of multi sensors
- Wide-range of communication technologies for sensor control and data acquisition
- Total station long distance measurement capability (up to 8 km)
- Meteorological network modeling over measurement area
- Computation of virtual sensors
- Flexible and customizable limit checks with multiple levels
- Powerful event management and messaging capabilities
- Visual and alphanumeric analysis
- Editing and reprocessing of total station data throughout data history
- Status overview using traffic light symbols over-laid on a photograph or map
- Import/Export to other systems (ASCII, DXF, WMF, standard Excel formats)
- Automatic backup and archive
SKU | Leica GeoMoS |
---|---|
MPN | Leica GeoMoS |
Brand | Leica Geosystems |
