GIS DataPRO

SKU: GIS DataPRO

GIS DataPRO

This GPS office software supports a number of GIS and CAD file formats. Use the GIS DataPRO to import and post process without a dongle device, interpolate reference station data, add, modify and delete reference stations.

Update reference your station database from Leica Geosystems' Web site, create post-processing report log files and much more.

Call or email for price

Tel: 01480 404888

Email: sales@sccssurvey.co.uk

This GPS office software supports a number of GIS and CAD file formats. Use the GIS DataPRO to import and post process without a dongle device, interpolate reference station data, add, modify and delete reference stations.

Update reference your station database from Leica Geosystems' Web site, create post-processing report log files and much more.

Credit Card Logos

Free Delivery

Send to a Colleague

Delivery and Returns

Follow us on LinkedIn

Price Match Promise

Delivery and Returns

SCCS
Description

Features at a Glance

  • Simple Dataflow from Field to Office
  • Native ESRI shapefile format - no export needed
  • SKI PRO post-processing, with available upgrades to phase processing
  • Simple and powerful Internet reference download
  • Export to 3D shapefiles, DWG, DXF, DGN, MIF and ASCII
  • Codelist creation for use with Leica GPS products
  • Raster Image support
  • Waypoint creation and file management for taking your data from the office to the field, for asset management
  • Powerful coordinate systems conversion



Leica GIS DataPRO in detail;

Office software to provide your GIS the best in GPSVersion 3.0: Software support for the GS20 and GS50 GPS receivers.
Leica's GIS DataPRO is a Windows™ based PC software to interface your GPS with your GIS office software. GIS DataPRO offers feature and attribute level controls, GPS post-processing, editing tools, and data export functions, all from an ESRI shapefile format. GIS DataPRO is a comprehensive solution for GIS and CAD users.

Post-Processing
Post-processing has never been easier or more flexible. Built on Leica Geosystems' Ski Pro post-processing engine, GIS DataPRO supports single and dual frequency code and phase post-processing. With a phase processing upgrade, GIS DataPRO and a Leica GPS unit can achieve centimeter-level accuracy. Whether you are a GPS novice or a power user, GIS DataPRO post-processing is flexible and powerful to meet your requirements.

  • Support of Leica GPS and industry standard RINEX data
  • Report generation for documentation and metadata
  • Static and Kinematic Processing ability


Internet Reference Download
Post-process even without your own reference station. By incorporating an easy to use Internet download wizard; you have one button access to download data from your closest GPS reference stations, and best of all, access is free! Using the SOPAC (Scripps orbit and permanent array centers) list of GPS reference stations, you are guaranteed unparalleled quality and reliable GPS reference data.

Bluetooth™ Wireless Data Transfer
In addition to handling removable flash memory and serial cable data transfers from all Leica GPS/GIS receivers, GIS DataPRO supports Bluetooth communication with the Leica GS20 data collector. This means transferring files to and from the GPS without cable or cumbersome docking station hardware.

Define Data Layers with Codelist Management
Define the structure of your geographic data before going into the field with the Codelist Manager. Define GIS data layers as point, line or polygon data and setup the attributes for each. Then create choice lists for fast data collection in the field or define critical attributes as mandatory so they don't get missed. If you have shapefile data already, create a codelist is as easy as importing a shapefile.

Data Export
GIS DataPRO is shapefile native and generates standard 2D ESRI shapefiles automatically. If you need your data in other formats Leica's export capabilities allow you to export your data to ASCII, AutoCAD™ (DWG and DXF), Microstation™ (DGN), MapInfo™ (MIF), and 3D shapefile formats; guarantying compatibility with most any software. Because DataPRO uses your prototype files for both settings and symbology, your data will automatically be in the format you need.

Additional Information
SKU GIS DataPRO
Brand SCCS
