AD12 Self Levelling Tribrach

SKU: 6901400

AD12 Self Levelling Tribrach

The automatic tripod AD-12 is used for automatic levelling of laser and surveying instruments, especially total stations. It can also be used for automatic levelling of any device up to 10kg. The levelling range is +/- 10 gon. Continuous levelling with precision of 10 mgon. All components incl. the servo motors, adjustment units, inclinometers, and the measuring and control electronics are integrated in the dust and waterproof casing. Setup: The automatic tripod AD-12 is fastened to a stand or platform with a central retaining 5/8“ screw. Notch marks allow for orientation along the axis. The theodolite or the total station is placed in the tripod positively centered and locked in position.

Horizontation area over 2 axis: up to +/-12 gon
on 1 axis: up to +/-18 gon
Horizontation precision +/- 10 mgon
Forced centering wild-system
Power supply 12 V=/0.11 A
Load carrying capacity up to 10 kg
Weight 6.3 kg
Guarantee 12 months

Availability: In stock

£4,320.00 inc VAT £3,600.00 excl VAT
£4,320.00 inc VAT £3,600.00 excl VAT
SCCS
Order by phone: 01480 404888
Call our experienced sales team to order or discuss any products.

The automatic tripod AD-12 is used for automatic levelling of laser and surveying instruments, especially total stations. It can also be used for automatic levelling of any device up to 10kg. The levelling range is +/- 10 gon. Continuous levelling with precision of 10 mgon. All components incl. the servo motors, adjustment units, inclinometers, and the measuring and control electronics are integrated in the dust and waterproof casing. Setup: The automatic tripod AD-12 is fastened to a stand or platform with a central retaining 5/8“ screw. Notch marks allow for orientation along the axis. The theodolite or the total station is placed in the tripod positively centered and locked in position.

Horizontation area over 2 axis: up to +/-12 gon
on 1 axis: up to +/-18 gon
Horizontation precision +/- 10 mgon
Forced centering wild-system
Power supply 12 V=/0.11 A
Load carrying capacity up to 10 kg
Weight 6.3 kg
Guarantee 12 months
